- CPU
AMD AM3+ FX™/Phenom™ II/Athlon™ II/Sempron™ 100 Series Processors
Supports CPU up to 140 W
AMD Cool 'n' Quiet™ Technology
- Chipset
AMD 760G (780L)/SB710
- Memory
4 x DIMM, Max. 32GB, DDR3 2000(O.C.)/1866(O.C.)/1800(O.C.)/1600(O.C.)/1333/1066 MHz ECC, Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows® OS when you want to install 4GB or more memory on the motherboard.
* AMD FX Series CPU on this motherboard supports up to DDR3 1866MHz as its standard memory frequency.
* AMD AM3 100 and 200 series CPU support up to DDR3 1066MHz.
- System Bus
Up to 5.2 GT/s HyperTransport™ 3
- Graphic
Integrated ATI Radeon™ HD 3000 GPU
Multi-VGA output support : HDMI/DVI/RGB ports *1
- Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz
- Supports DVI with max. resolution 2560 x 1600 @ 60 Hz
- Supports RGB with max. resolution 2560 x 1440 @ 75 Hz
Maximum shared memory of 1024 MB
Hybrid CrossFireX™ Support
- Expansion Slots
1 x PCIe x16
1 x PCIe x1
2 x PCI
- Storage
Built-in Controller :
6 x SATA 3Gb/s port(s), blue
Support Raid 0, 1, 10, JBOD
- LAN
Realtek®, 1 x Gigabit LAN Controller(s)
- Audio
VIA VT1708S 8-Channel High Definition Audio CODEC
- USB Ports
Built-in Controller :
10 x USB 2.0 port(s) (4 at back panel, black, 6 at mid-board)
Built-in Controller :
2 x USB 3.0 port(s) (2 at back panel, blue)
- ROG Exclusive Features
Overclocking Protection :
- ASUS C.P.R.(CPU Parameter Recall)
- Special Features
ASUS EPU :
- EPU
Turbo Key
Core Unlocker
ASUS Exclusive Features :
- Ai Charger
- Anti-Surge
ASUS Quiet Thermal Solution :
- ASUS Q-Fan
ASUS EZ DIY :
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
- Back I/O Ports
1 x PS/2 keyboard/mouse combo port(s)
1 x DVI
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.0
4 x USB 2.0
1 x Optical S/PDIF out
6 x Audio jack(s)
- Internal I/O Ports
3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
1 x COM port(s) connector(s)
6 x SATA 3Gb/s connector(s)
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 4-pin ATX 12V Power connector(s)
1 x parallel port connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s)
- Accessories
User's manual
I/O Shield
2 x SATA 3Gb/s cable(s)
- BIOS
16 Mb Flash ROM, AMI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS V2.5, ACPI V2.0a
- Support Disc
Drivers
ASUS PC Probe II
ASUS Update
Anti-virus software (OEM version)
- Form Factor
uATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
